Composed of 19/32 stranded nickel-plated copper conductors with mineral filled polytetrafluoroethylene (PTFE) insulation and jacket.. These cables are rated for a voltage of 600 volts, have a maximum temperature of 260???C, and weigh approximately 8.10 lbs/MFT.
Conductor Stranding: 19/32
No. of Strands: 19
Strand Size: 32
Nom. Dia. of Cond.: 0.038
Min O.D. (in): 0.080
Max O.D. (in): 0.084
Approx LBS/MFT: 8.10
M27500 Component: TA
Mil-Spec: M22759/8
SAE Spec: AS22759/8
Cond. Material: Nickel-Plated Copper
Insul. Material: Mineral Filled Polytetrafluoroethylene (PTFE)
Min. Temp: -55???C
Max. Temp: 260???C
Unit of Measure: FEET
Supplier/Manufacturer SKU: M22759/8-20-9
Mil Spec, TSO, Certification: M22759/8-20-9
HS Code: 8544.11.0050
HAZMAT:
UN#:
