The 7000 series miniature toggle switch has silver contact solder lug terminations. The threaded bushing is designed for panel mount installations with 1/4" opening.
Version 7203SH3ZQE is a double-pole, double-throw miniature toggle switch. Positions: ON-OFF-ON
- Threaded panel mount
- 10mΩ at 2 to 4VDC Initial contact resistance
- 10⁹Ω Minimum insulation resistance
- 1000VRMS at sea level Minimum dielectric strength
- Epoxy terminal-seal compatible with bottom wash cleaning
- RoHS Compliant
- Life: 100,000 make-and-break cycles at full load
Unit of Measure: EACH
Supplier/Manufacturer SKU: 7203SH3ZQE
Mil Spec, TSO, Certification:
HS Code:
HAZMAT:
UN#:
