Straight, TNC crimp connector jack for use with RG142, RG400 and RG-55/U (cable group C1) coaxial cable. 50 ohms Gold-plated, center contact Delrin dielectric material.
The TNC connector series is a miniature, threaded weatherproof series with a constant 50 Ω impedance and a frequency range of DC to 11 GHz. The TNC series shares its contact design with the BNC series, utilizing a threaded coupling nut for secure mating and higher frequency performance than the BNC.
TNC connectors are produced with standard and reverse polarity. Reverse polarity is a keying system accomplished with a reverse interface, and ensures that reverse polarity interface connectors do not mate with standard interface connectors. Amphenol accomplishes this by inserting female contacts into plugs and male contacts into jacks to ensure quality. Other manufacturers may use reverse threading to accomplish reverse polarity keying.
Features
- Threaded coupling interface ensures connector with not de-couple in vibration-intense applications
- Durable construction
- Expansive product line includes designs for many common cable types
Specifications
Body Material: Brass
