NYLO-Seal Nylon tube fittings have excellent resistance to acids, oils and greases. Installation time is reduced with NYLO-Seal fittings when compared to regular compression or flare fittings. When being tightened, stress is relieved as the nut revolves around the sleeve which prevents torque from being transmitted to the tubing. These fittings can continuously operate at temperatures of 200degF and intermittently at temperature as high as 250degF. NYLO-Seal Nylon fittings are excellent for instrument, lubricant, air, hydrocarbon fuel, oil coolant, low pressure hydraulic lines, laboratory, and chemical applications.
- For use with pitot static tubing
- 0.375 inch outside diameter
- Nylon material
- Secure fit
- Anti-vibration
- Excellent resistance to chemicals
- Reduces installation time
- Eliminates stress on plastic tubing during installation
- Exceptionally strong and resistant to abuse
- Continual Operation at temperatures as high as 200degF
- Couples most types of thermoplastic tubing
- Designed for instrument, lubricant, air, hydrocarbon fuel, oil coolant, low pressure hydraulic lines, laboratory, and chemical applications
Tube Size: 3/8 in
Maximum Working Pressure: 250 PSI
Operating temperature: 200degF continuous; 250degF intermittently
Materials: Molded Nylon Bodies and Nuts, and Acetal Copolymer Sleeves
Compatible Tubing: NYLO-Seal fittings can be used to couple to most types of thermo plastic tubing
