Home CONNECTOR | TNC Male, Crimp/Solder, Straight, Low PIM, ECS 311201, 421201

CONNECTOR | TNC Male, Crimp/Solder, Straight, Low PIM, ECS 311201, 421201

Out of stock
Product code: CTSP122
$0.00

Body Material:  Brass per ASTM B16

Bulkhead (Y/N):  No

Cable:  311201, 421201

Center Contact Material:  Brass Per ASTM B16

Ferrule Material:  Annealed Brass Per ASTM B16

Frequency Range:  0-11 GHz

Impedance (Ohms):  50 OHMS Nominal

Inner Contact Termination Style: Solder

Outer Contact Termination Style: Crimp

Insertion Loss:  .1 dB maximum DC to 2Ghz

Temperature Rating (°C):  -65 to +165 C

VSWR:  1.2:1 Maximum DC to 2GHz
