Home COAX CABLE | GigaFlight Low Loss 75 Ohm HD White Coaxial Cable

COAX CABLE | GigaFlight Low Loss 75 Ohm HD White Coaxial Cable

Out of stock
Product code: GF7-303D

The GF7-303D is a form, fit, and function drop-in replacement for the commonly used PIC V76261. Meaning the electrical performance, size/weight, connector usage, and the applications are the same. The GF7-303D is not only recommended for use in SMPTE 259M, but also can be used in the SMPTE 292 and SMTPE 424 video applications.

$0.00

Outer Diameter in (mm):  0.125 (3.05)
Weight lbs/1000ft (kg/1000m):  11 (16)
Operating Temperature:  -55°C to +150°C
Minimum Bend Radius in (mm):  0.64 (16.26)
SMPTE 292M HD-SDI ft (m) (Max Length):  120 (36.6)
SMPTE 424M 3G-SDI ft (m) (Max Length):  80 (24.4)

Unit of Measure: FEET
Supplier/Manufacturer SKU: GF7-303D
Mil Spec, TSO, Certification:
HS Code:
HAZMAT:
UN#:
