TI10 DC to AC Inverter, 11–40VDC in, 26VAC out, 10VA, Sine Wave

The TI10 DC-to-AC inverter provides 26-volt, 400 Hz AC power. The voltage and frequency of its pure sine wave output remains stable regardless of input fluctuations. The TI10 is small and lightweight for convenient installation in your aircraft and is FAA PMA approved.

• Compatible with 14 and 28 VDC aircraft (11 – 40 VDC input range)
• Pure sine wave output 26 VAC, 400 Hz, 10 VA
• Provides reference and/or power for bootstrap synchros, weather radar systems, GAD 42, GAD 43 and others
• Transient and reverse polarity protected
• Small size (1.5 x 2.8 x 3.0 inches)
• Lightweight (0.28 lbs)
• FAA PMA approved
• Designed and built in Wichita, Kansas, USA
• Two-year limited warranty

Input Voltage
11 – 40 VDC

Input Current
1.7A max (at 11 VDC input, 10 VA load)

Output Voltage
26 ± 1 VAC, 400 Hz ± 0.5%, single phase

Output Power
10 VA Pure sine wave, < 3% distortion

Weight
0.28 lbs

Altitude
–1,000 to +50,000 feet

Humidity
0 to 95% at 25°C

Temperature
–55°C to +70°C

Dimensions
1.5” H x 2.8” L x 3.0” W (approximate)

RF Emissions
RTCA DO-160F, Section 21, Category M

Vibration
.02 in. dbl. ampl., 3g @ 5 to 55 Hz

Connector
Terminal block

Mounting
Base mount

Certification
FAA PMA approved
